Egis TH3 Series Automatic Charging Relays
Reference:
6601B
Egis TH3 Series Automatic Charging Relays
Egis TH3 automatic charging relays share charge between batteries and isolate them when no source is present - eliminating dead start batteries. Dual isolation inputs support twin engines or independent chargers, with start assist and shorted-cell lock-out.
Key Features & Upfitter Specs
- Options On This Page: 7610B 12 V and 7610-24B 24 V 160 A ACRs, 7612B 12 V and 7612-24B 24 V dual 2x80 A ACRs, and the 6601B 140 A mini ACR.
- Ratings: 1.3 mA off-state draw versus 7-10 mA typical; sealed IP67; integrated thermal shutdown; DTM connector harness included.
- Extras: Start assist input and a low-amp status output for remote indication or a secondary relay.
- Warranty: 4-year Egis warranty.
Specifications
| Configuration | Mini Automatic Charging Relay (ACR), 140 A / 12V, Automatic Charging Relay (ACR), 160 A / 24V, Automatic Charging Relay (ACR), 160 A / 12V, Dual Automatic Charging Relay (ACR), 2x80 A / 24V, Dual Automatic Charging Relay (ACR), 2x80 A / 12V |
| Manufacturer | Egis |
| Tags | |
|---|---|
| Tags |
|
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Part Numbers & Pricing 5 part numbers
Approved resellers see discounted pricing in this table after signing in.
Apply for a reseller account
Sign in
| Part Number | Manufacturer | Configuration | Price | Select |
|---|---|---|---|---|
6601B
|
Egis | Mini Automatic Charging Relay (ACR), 140 A / 12V | $ 1.00 | |
7610-24B
|
Egis | Automatic Charging Relay (ACR), 160 A / 24V | $ 1.00 | |
7610B
|
Egis | Automatic Charging Relay (ACR), 160 A / 12V | $ 1.00 | |
7612-24B
|
Egis | Dual Automatic Charging Relay (ACR), 2x80 A / 24V | $ 1.00 | |
7612B
|
Egis | Dual Automatic Charging Relay (ACR), 2x80 A / 12V | $ 1.00 |
No part numbers match your filter.
Prices are per unit on your current pricelist, excluding tax and shipping. Select a row to add that part number to your cart.
