Egis RT Series Fuse Blocks
Reference:
8023-04B
Egis RT Series Fuse Blocks
Egis RT Series fuse blocks are the modular workhorse for branch circuits - ATO/ATC positions with blown-fuse LEDs, stainless self-locking hardware and optional ground busbars that let two part numbers build seven configurations.
Key Features & Upfitter Specs
- Options On This Page: 6, 12 and 18 circuit blocks with or without ground bus, 4/6/8 circuit covered blocks, the 8030B 12 circuit ground bus bar, and the 8023 ring terminal battery-mount fuse block and busbar kits.
- Ratings: 100 A per block, 30 A per circuit, #10 AWG max output wire, 0-36 VDC; ATO / ATC / ATF fuses 1-40 A.
- Diagnostics: Blown fuse LEDs and spare fuse locations speed troubleshooting.
- Labels: Optional weather-proof label sets in standard or custom versions.
- Warranty: 4-year Egis warranty.
Specifications
| Configuration | Ring Terminal Fuse Block and Busbar Kit, Battery Mount, Battery Terminal Mount Fuse Block 4 Circuit, Fuse Block 6 Circuit with Ground, Fuse Block 12 Circuit with Ground, Fuse Block 6 Circuit, Fuse Block 12 Circuit, 12 Circuit Ground Bus Bar, Fuse Block 18 Circuit with Ground, Fuse Block 18 Circuit, Fuse Block 6 Independent Circuits with Cover with 2xJumpers, Fuse Block 4 Circuits with Cover, Fuse Block 8 Circuits with Cover |
| Manufacturer | Egis |
| Tags | |
|---|---|
| Tags |
|
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Part Numbers & Pricing 12 part numbers
Approved resellers see discounted pricing in this table after signing in.
Apply for a reseller account
Sign in
| Part Number | Manufacturer | Configuration | Price | Select |
|---|---|---|---|---|
8023-04B
|
Egis | Ring Terminal Fuse Block and Busbar Kit, Battery Mount | $ 1.00 | |
8023B
|
Egis | Battery Terminal Mount Fuse Block 4 Circuit | $ 1.00 | |
8025B
|
Egis | Fuse Block 6 Circuit with Ground | $ 1.00 | |
8026B
|
Egis | Fuse Block 12 Circuit with Ground | $ 1.00 | |
8028B
|
Egis | Fuse Block 6 Circuit | $ 1.00 | |
8029B
|
Egis | Fuse Block 12 Circuit | $ 1.00 | |
8030B
|
Egis | 12 Circuit Ground Bus Bar | $ 1.00 | |
8031B
|
Egis | Fuse Block 18 Circuit with Ground | $ 1.00 | |
8032B
|
Egis | Fuse Block 18 Circuit | $ 1.00 | |
8037B
|
Egis | Fuse Block 6 Independent Circuits with Cover with 2xJumpers | $ 1.00 | |
8045B
|
Egis | Fuse Block 4 Circuits with Cover | $ 1.00 | |
8046B
|
Egis | Fuse Block 8 Circuits with Cover | $ 1.00 |
No part numbers match your filter.
Prices are per unit on your current pricelist, excluding tax and shipping. Select a row to add that part number to your cart.
